Intel Core i7-680UM

Intel 680UM

Le Intel Core i7-680UM est un CPU « Ultra Low Voltage dual-core » pour petits portables. Il est cadencé entre 1.47 et 2.5 GHz (avec le Turbo Boost). Le 680UM est le CPU ULV le plus puissant de fin 2010. C'est un CPU Nehalem (Westemere). L'Hyperthreading permet de gérer 4 processeurs. Comparé au Core i7-640M et au i7 640LM, le 680UM est plus lent mais moins gourmand.

Les nouveaux Core i7-680UM possède un GPU intégré nommé GMA HD et un contrôleur mémoire DDR3. Tout deux sur une puce séparé et gravée en 45nm alors que le CPU est gravé en 32nm.

Avec le contrôleur mémoire intégré, l'HyperThreading et le Turbo Boost, le Core i7-680UM est plus rapide qu'un Core 2 Duo (1.4 GHz) dans tout les benchmarks. Mais il ne dépassera que rarement les 2.53 GHz à cause des design trop courts dans les portables. Donc en moyenne on est au niveau des Core 2 Duo à 2.6 GHz en application mono-core.

La gravure 32nm de la génération Westmere comprend l'encryptage AES. Ces instructions permettent de meilleures performances en réseau (Avec le test Communications Suite de PCMark Vantage le score monte de 70% avec le Core i5-520M).

Le GPU intégré Intel Graphics Media Accelerator HD (GMA HD) est cadencé entre 266 et 566 MHz (Turbo Boost) donc plus rapide que la moyenne. Avec des performances plus élevées que celles de la GMA 4500MHD.

GammeIntel Core i7
Nom de codeArrandale

Gamme: Core i7 Arrandale

Intel Core i7-640M2.8 - 3.46 GHz2 / 4 cores4 MB L3
Intel Core i7-620M2.66 - 3.33 GHz2 / 4 cores4 MB L3
Intel Core i7-660LM2.27 - 3.07 GHz2 / 4 cores4 MB L3
Intel Core i7-640LM2.13 - 2.93 GHz2 / 4 cores4 MB L3
Intel Core i7-620LM2 - 2.8 GHz2 / 4 cores4 MB L3
Intel Core i7-680UM « 1.47 - 2.53 GHz2 / 4 cores4 MB L3
Intel Core i7-660UM1.33 - 2.4 GHz2 / 4 cores4 MB L3
Intel Core i7-640UM1.2 - 2.27 GHz2 / 4 cores4 MB L3
Intel Core i7-620UM1.06 - 2.13 GHz2 / 4 cores4 MB L3
Fréquence1467 - 2533 MHz
Bus système2500
Cache de Niveau 2 (L2)512 KB
Cache de Niveau 3 (L3)4 MB
Nombres de cœurs/threads simultanés supportés2 / 4
Consommation énergétique maximale (TDP)18 Watt(s)
Nombre de transistors382+177 Million(s)
Lithographie (procédé de fabrication)32 nm
Taille du Die81+144 mm2
Température maximale105 °C
SocketBGA1288
FonctionnalitésTurbo Boost (2.53 GHz max), Hyper Threading, Enhanced Speedstep, integrierte GMA HD 166-500MHz,
64 BitPrend en charge les instructions 64 Bit
Architecturex86
Prix de départ$317 U.S.
Date de présentation09/26/2010
Lien redirigeant vers une page externe du produitark.intel.com
