Intel Core i7-660UM

Intel 660UM

Le Intel Core i7-660UM est un dual core Ultra Low Voltage pour portables légers. Il est cadencé de 1.33 - 2.4 GHz (avec Turbo Boost). Le CPU est basé sur la famille Nehalem (Westemere). L'Hyperthreading permet au Dual Core de gérer 4 processeurs en tout.Comparé au Core i7-620M et 640LM, le 660UM est plus lent mais consomme moins.

Le Core i7-660UM possède une carte graphique intégrée (Intel HD Graphics) et un contrôleur mémoire intégré. Ils sont sur des puces séparées de 45nm alors que le CPU est gravé en 32nm.

Grâce au contrôleur mémoire intégré, l'HyperThreading et le Turbo Boost, le Core i5-660UM est plus puissant à même fréquence que les Core 2 Duo (1.33 GHz) dans toutes les applications. Le I7-660UM reste bien plus puissant que les Core 2 Duo SL9300 (1.6GHz).

Les cores gravés en 32nm de la génération Westmere supporte l'accélération matérielle des codes AES. Les applications qui gèrent ces fonctions sont grandement accélérées.

La Intel Graphics Media Accelerator HD (GMA HD) est cadencée entre 166 et 500 MHz (Turbo Boost) donc assez puissant. C'est toujours mieux que la GMA 4500MHD.

GammeIntel Core i7
Nom de codeArrandale

Gamme: Core i7 Arrandale

Intel Core i7-640M2.8 - 3.46 GHz2 / 4 cores4 MB L3
Intel Core i7-620M2.66 - 3.33 GHz2 / 4 cores4 MB L3
Intel Core i7-660LM2.27 - 3.07 GHz2 / 4 cores4 MB L3
Intel Core i7-640LM2.13 - 2.93 GHz2 / 4 cores4 MB L3
Intel Core i7-620LM2 - 2.8 GHz2 / 4 cores4 MB L3
Intel Core i7-680UM1.47 - 2.53 GHz2 / 4 cores4 MB L3
Intel Core i7-660UM « 1.33 - 2.4 GHz2 / 4 cores4 MB L3
Intel Core i7-640UM1.2 - 2.27 GHz2 / 4 cores4 MB L3
Intel Core i7-620UM1.06 - 2.13 GHz2 / 4 cores4 MB L3
Fréquence1333 - 2400 MHz
Bus système2500
Cache de Niveau 2 (L2)512 KB
Cache de Niveau 3 (L3)4 MB
Nombres de cœurs/threads simultanés supportés2 / 4
Consommation énergétique maximale (TDP)18 Watt(s)
Nombre de transistors382+177 Million(s)
Lithographie (procédé de fabrication)32 nm
Taille du Die81+144 mm2
Température maximale105 °C
SocketBGA1288
FonctionnalitésTurbo Boost (2.40 GHz max), Hyper Threading, Enhanced Speedstep, integrierte GMA HD 166-500MHz,
64 BitPrend en charge les instructions 64 Bit
Architecturex86
Date de présentation09/01/2010

Benchmarks

- Amplitude des valeurs obtenues dans le benchmark avec cette carte graphique
- Valeur moyenne obtenue dans le benchmark avec cette carte graphique
* Plus les chiffres sont petits, plus les performances sont élevées
