Notebookcheck Logo

Intel Core i5-520UM

Intel 520UM

Le Intel Core i5-520UM est un dual core Ultra Low Voltage pour portables légers. Il est cadencé de 1.06 à 1.86 GHz (avec Turbo Boost). Le CPU est basé sur la famille Nehalem (Westemere). L'Hyperthreading permet au Dual Core de gérer 4 processeurs en tout.Comparé au Core i7-620M et 640LM, le 520UM est plus lent mais consomme moins.

Le Core i5-520UM possède une carte graphique intégrée (Intel HD Graphics) et un contrôleur mémoire intégré. Ils sont sur des puces séparées de 45nm alors que le CPU est gravé en 32nm.

Grâce au contrôleur mémoire intégré, l'HyperThreading et le Turbo Boost, le Core i5-520UM est plus puissant à même fréquence que les Core 2 Duo (1.06 GHz) dans toutes les applications. Le I7-640UM reste bien plus puissant que les Core 2 Duo SL9300 (1.6GHz).

Les cores gravés en 32nm de la génération Westmere supporte l'accélération matérielle des codes AES. Les applications qui gèrent ces fonctions sont grandement accélérées.

La Intel Graphics Media Accelerator HD (GMA HD) est cadencée entre 166 et 500 MHz (Turbo Boost) donc assez puissant. C'est toujours mieux que la GMA 4500MHD.

Avec sa consommation de 18 Watt (max.) pour tout le pack, soit bien mieux que les 17 Watt des Core 2 Duo SL mais en comptant uniquement le CPU.

GammeIntel Core i5
Nom de codeArrandale

Gamme: Core i5 Arrandale

Intel Core i5-580M2.67 - 3.33 GHz2 / 4 cores3 MB L3
Intel Core i5-560M2.67 - 3.2 GHz2 / 4 cores3 MB L3
Intel Core i5-480M2.67 - 2.93 GHz2 / 4 cores3 MB L3
Intel Core i5-540M2.53 - 3.07 GHz2 / 4 cores3 MB L3
Intel Core i5-460M2.53 - 2.8 GHz2 / 4 cores3 MB L3
Intel Core i5-520M2.4 - 2.93 GHz2 / 4 cores3 MB L3
Intel Core i5-450M2.4 - 2.66 GHz2 / 4 cores3 MB L3
Intel Core i5-430M2.26 - 2.53 GHz2 / 4 cores3 MB L3
Intel Core i5-560UM1.33 - 2.13 GHz2 / 4 cores3 MB L3
Intel Core i5-470UM1.33 - 1.87 GHz2 / 4 cores3 MB L3
Intel Core i5-540UM1.2 - 2 GHz2 / 4 cores3 MB L3
Intel Core i5-520UM « 1.06 - 1.87 GHz2 / 4 cores3 MB L3
Intel Core i5-430UM1.2 - 1.73 GHz2 / 4 cores3 MB L3
Fréquence1060 - 1866 MHz
Bus système2500
Cache de Niveau 2 (L2)512 KB
Cache de Niveau 3 (L3)3 MB
Nombres de cœurs/threads simultanés supportés2 / 4
Consommation énergétique maximale (TDP)18 Watt(s)
Nombre de transistors382+177 Million(s)
Lithographie (procédé de fabrication)32 nm
Taille du Die81+114 mm2
Température maximale105 °C
SocketBGA1288
FonctionnalitésTurbo Boost (1.86 GHz max), Hyper Threading, Enhanced Speedstep, integrierte GMA HD 166-500MHz,
64 BitPrend en charge les instructions 64 Bit
Architecturex86
Prix de départ$241 U.S.
Date de présentation01/04/2010
Lien redirigeant vers une page externe du produitark.intel.com

Benchmarks

Cinebench R11.5 - Cinebench R11.5 CPU Multi 64 Bit
min: 1.02     moyenne: 1.2     médian: 1.2 (2%)     maximum: 1.33 Points
Cinebench R10 - Cinebench R10 Rend. Single (32bit)
min: 1471     moyenne: 1981     médian: 1942.5 (12%)     maximum: 2569 points
Cinebench R10 - Cinebench R10 Rend. Multi (32bit)
min: 2785     moyenne: 3670     médian: 3778 (3%)     maximum: 4340 points
Cinebench R10 - Cinebench R10 Rend. Multi (64bit)
min: 3946     moyenne: 4600     médian: 4632.5 (3%)     maximum: 5187 Points
Cinebench R10 - Cinebench R10 Rend. Single (64bit)
min: 2263     moyenne: 2561     médian: 2423.5 (3%)     maximum: 3135 Points
wPrime 2.10 - wPrime 2.0 1024m *
min: 995     moyenne: 1110     médian: 1110 (13%)     maximum: 1225 s
wPrime 2.10 - wPrime 2.0 32m *
min: 31.8     moyenne: 35.2     médian: 35.2 (7%)     maximum: 38.5 s
3DMark 06 - CPU - 3DMark 06 - CPU
min: 982     moyenne: 1429     médian: 1492 (3%)     maximum: 1718 Points
Super Pi mod 1.5 XS 1M - Super Pi mod 1.5 XS 1M *
min: 24     moyenne: 26.7     médian: 25 (5%)     maximum: 31 s
Super Pi mod 1.5 XS 2M - Super Pi mod 1.5 XS 2M *
min: 56     moyenne: 62.3     médian: 58 (2%)     maximum: 73 s
Super Pi Mod 1.5 XS 32M - Super Pi mod 1.5 XS 32M *
min: 1303     moyenne: 1439     médian: 1341 (6%)     maximum: 1674 s
PCMark 05 - PCMark 05 - Standard
min: 2848     moyenne: 3571     médian: 3925 (8%)     maximum: 3940 Points
Windows 7 Experience Index - Win7 CPU
min: 3.9     moyenne: 4.7     médian: 4.8 (61%)     maximum: 5.4 Points
3DMark Vantage - 3DM Vant. Perf. CPU no Physx
min: 3751     moyenne: 4065     médian: 4064.5 (4%)     maximum: 4378 Points
- Amplitude des valeurs obtenues dans le benchmark avec cette carte graphique
- Valeur moyenne obtenue dans le benchmark avec cette carte graphique
* Plus les chiffres sont petits, plus les performances sont élevées
