NVIDIA Quadro P5200
La Nvidia Quadro P5200 est une carte graphique haut de gamme pour stations de travail. Similaire à la GeForce GTX 1080 grand public, elle est basée sur une puce GP104 avec 2 560 nuanceurs, mais utilise de la GDDR5 plus lente que la GDDR5X de la GTX 1080. La Quadro P5200 succède à la Quadro P5000. Il y aura une version normale (Max-P) et une version moins puissante mais plus efficiente (Max-Q). Pour la version Max-P, la fréquence est comprise entre 1 556 (de base) et 1 746 MHz (boost), et entre 1 316 (de base) et 1 569 MHz (boost) pour la version Max-Q (-15 % / -10 %), d'après une capture d'écran GPU-Z d'un lecteur. Les 16 Go de GDDR5 sont cadencés à 3,6 GHz, avec une bande passante de mémoire de 230 Go/s.
Les cartes graphiques Quadro possèdent des pilotes certifiés, optimisés pour la stabilité et les performances dans les logiciels professionnels (CAD, DCC, médical, prospection, et visualisation). Les performances dans ces domaines sont bien meilleures qu'avec les GPU grand public équivalents.
Les performances théoriques devraient être un peu supérieures à celles de l'ancienne Quadro P5000. La fréquence n'est pas encore connue, mais il semblerait que la consommation soit bien supérieure, ce qui devrait conduire à des performances en hausse. Nvidia indique un pic de performances théorique de 8,9 GFLPS (Single Precision).
La consommation énergétique de la Quadro P5200 est de 150 W (Max-P) selon Nvidia, et devrait être de 100 - 110 W pour la version Max-Q. C'est de ce fait bien plus élevé que pour la Quadro P5000 (100 et 80 W).
Quadro P Gamme Quadro P5200 2560 @ 1.32 - 1.57 GHz 256 Bit @ 7216 MHz Quadro P4200 2304 @ 1.22 - 1.48 GHz 256 Bit @ 7132 MHz Quadro P5000 2048 @ 1.16 - 1.51 GHz 256 Bit @ 6006 MHz Quadro P5000 Max-Q 2048 @ 1.1 - 1.37 GHz 256 Bit @ 6006 MHz Quadro P4000 1792 @ 1.2 - 1.23 GHz 256 Bit @ 6006 MHz Quadro P4000 Max-Q 1792 @ 1.11 - 1.24 GHz 256 Bit @ 6006 MHz Quadro P3200 1792 @ 0.71 - 1.23 GHz 192 Bit @ 7008 MHz Quadro P3000 1280 @ 1.09 - 1.22 GHz 192 Bit @ 7008 MHz Quadro P3000 Max-Q 1280 @ 1.08 - 1.24 GHz 192 Bit @ 7008 MHz Quadro P2000 768 @ 1.22 - 1.47 GHz 128 Bit @ 6008 MHz Quadro P2000 Max-Q 768 @ 1.22 - 1.47 GHz 128 Bit @ 6008 MHz Quadro P1000 512 @ 1.49 - 1.52 GHz 128 Bit @ 6008 MHz Quadro P620 512 @ 1.18 - 1.44 GHz 128 Bit @ 6000 MHz
Architecture Pascal Pipelines 2560 - unifiés Fréquence du noyau interne 1316 - 1569 (Boost) MHz Fréquence de la mémoire 7216 MHz Largeur du bus mémoire 256 Bit Type de mémoire GDDR5 Quantité maximale possible de mémoire embarquée 16 GB Mémoire partagée non API DirectX 12_1, Shader 5.0, OpenGL 4.5 Consommation d'énergie 150 Watt(s) technologie 16 nm Caractéristiques Optimus,
PhysX, 3D Vision Pro, nView, Optimus Dimension de l'ordinateur portable de grandes dimensions (en remplacement d'un ordinateur de bureau) Date de présentation 11.01.2017
Benchmarks Performance Rating - 3DMark 11 + Fire Strike + Time Spy
34.3 pt (35%)
...
NVIDIA GeForce GTX 1070 Mobile
NVIDIA GeForce RTX 4060 Laptop GPU
...
NVIDIA GeForce RTX 4090 Laptop GPU
3DMark - 3DMark Time Spy Score
min: 6580 moyenne: 6647 médian: 6646.5 (20%) maximum: 6713 Points
...
NVIDIA GeForce RTX 2070 Super Max-Q
...
NVIDIA GeForce RTX 4090 Laptop GPU
3DMark - 3DMark Time Spy Graphics
min: 6390 moyenne: 6422 médian: 6422 (17%) maximum: 6454 Points
...
NVIDIA GeForce GTX 1070 Mobile
NVIDIA GeForce RTX 2070 Super Max-Q
...
NVIDIA GeForce RTX 4090 Laptop GPU
3DMark - 3DMark Cloud Gate Score
min: 39077 moyenne: 43444 médian: 43443.5 (47%) maximum: 47810 Points
...
NVIDIA GeForce RTX 2070 Super Mobile
NVIDIA GeForce RTX 2070 Super Max-Q
...
3DMark - 3DMark Cloud Gate Graphics
min: 105184 moyenne: 106328 médian: 106328 (28%) maximum: 107472 Points
...
NVIDIA GeForce GTX 1070 Mobile
NVIDIA GeForce RTX 2070 Super Max-Q
NVIDIA GeForce RTX 2070 Super Mobile
...
NVIDIA GeForce RTX 4060 Laptop GPU
3DMark - 3DMark Fire Strike Standard Score
min: 16528 moyenne: 16626 médian: 16625.5 (29%) maximum: 16723 Points
...
NVIDIA GeForce GTX 1070 Mobile
NVIDIA GeForce RTX 2070 Super Max-Q
...
NVIDIA GeForce RTX 4090 Laptop GPU
3DMark - 3DMark Fire Strike Standard Graphics
min: 18390 moyenne: 18467 médian: 18467 (21%) maximum: 18544 Points
...
NVIDIA GeForce GTX 1070 Mobile
NVIDIA GeForce RTX 2070 Super Max-Q
...
NVIDIA GeForce RTX 4090 Laptop GPU
3DMark - 3DMark Ice Storm Graphics
387870 Points (51%)
...
NVIDIA GeForce RTX 4080 Laptop GPU
AMD Radeon RX 7600S
...
NVIDIA GeForce RTX 4090 Laptop GPU
3DMark 11 - 3DM11 Performance Score
min: 21204 moyenne: 21715 médian: 21715 (31%) maximum: 22226 Points
...
NVIDIA GeForce RTX 2070 Super Max-Q
NVIDIA GeForce RTX 2070 Super Mobile
...
NVIDIA GeForce RTX 4090 Laptop GPU
3DMark 11 - 3DM11 Performance GPU
min: 24934 moyenne: 25100 médian: 25100 (22%) maximum: 25266 Points
...
NVIDIA GeForce GTX 1070 Mobile
NVIDIA GeForce RTX 2070 Super Max-Q
...
NVIDIA GeForce RTX 4090 Laptop GPU
3DMark Vantage 3DM Vant. Perf. total + 3DMark Vantage - 3DM Vant. Perf. total
65844 Points (19%)
...
NVIDIA GeForce RTX 2070 Super Max-Q
NVIDIA GeForce RTX 2080 Super Mobile
NVIDIA GeForce RTX 2070 Super Mobile
...
NVIDIA GeForce RTX 4090 Laptop GPU
3DM Vant. Perf. GPU no PhysX + 3DMark Vantage - 3DM Vant. Perf. GPU no PhysX
68614 Points (40%)
...
NVIDIA GeForce RTX 2070 Super Max-Q
NVIDIA GeForce RTX 2070 Super Mobile
NVIDIA GeForce RTX 2080 Super Mobile
...
NVIDIA GeForce RTX 4090 Laptop GPU
3DMark 06 3DMark 06 - Standard 1280x1024 +
44390 Points (62%)
...
NVIDIA GeForce RTX 2080 Super Mobile
NVIDIA GeForce RTX 2070 Super Mobile
NVIDIA GeForce RTX 2070 Super Max-Q
AMD Radeon RX 7600S
...
NVIDIA GeForce RTX 4090 Laptop GPU
SPECviewperf 12 specvp12 sw-03 + SPECviewperf 12 - specvp12 sw-03
min: 199.8 moyenne: 205.9 médian: 205.9 (57%) maximum: 212 fps
...
specvp12 snx-02 + SPECviewperf 12 - specvp12 snx-02
min: 213.7 moyenne: 215.8 médian: 215.8 (54%) maximum: 217.9 fps
...
specvp12 showcase-01 + SPECviewperf 12 - specvp12 showcase-01
min: 75 moyenne: 75.3 médian: 75.3 (16%) maximum: 75.6 fps
...
NVIDIA GeForce GTX 1070 Mobile
...
specvp12 mediacal-01 + SPECviewperf 12 - specvp12 mediacal-01
min: 79.1 moyenne: 79.3 médian: 79.3 (23%) maximum: 79.4 fps
...
specvp12 maya-04 + SPECviewperf 12 - specvp12 maya-04
min: 143.4 moyenne: 145.7 médian: 145.7 (40%) maximum: 147.9 fps
...
...
specvp12 energy-01 + SPECviewperf 12 - specvp12 energy-01
16.9 fps (18%)
...
specvp12 creo-01 + SPECviewperf 12 - specvp12 creo-01
min: 152 moyenne: 156 médian: 156 (79%) maximum: 160 fps
...
specvp12 catia-04 + SPECviewperf 12 - specvp12 catia-04
min: 188.6 moyenne: 192.6 médian: 192.6 (36%) maximum: 196.6 fps
...
SPECviewperf 13 specvp13 sw-04 + SPECviewperf 13 - specvp13 sw-04
min: 178.3 moyenne: 183.8 médian: 183.8 (57%) maximum: 189.2 fps
Intel Iris Plus Graphics G7 (Ice Lake 64 EU)
...
NVIDIA GeForce RTX 4090 Laptop GPU
specvp13 snx-03 + SPECviewperf 13 - specvp13 snx-03
min: 386.7 moyenne: 391.5 médian: 391.5 (54%) maximum: 396.3 fps
...
specvp13 showcase-02 + SPECviewperf 13 - specvp13 showcase-02
min: 74.7 moyenne: 75.1 médian: 75.1 (16%) maximum: 75.5 fps
...
AMD Radeon RX 5300M
NVIDIA GeForce RTX 4050 Laptop GPU
NVIDIA GeForce RTX 2070 Super Max-Q
...
NVIDIA GeForce RTX 4090 Laptop GPU
specvp13 medical-02 + SPECviewperf 13 - specvp13 medical-02
min: 61.5 moyenne: 61.6 médian: 61.6 (23%) maximum: 61.7 fps
...
NVIDIA GeForce RTX 2070 Super Mobile
NVIDIA GeForce RTX 4050 Laptop GPU
NVIDIA GeForce RTX 2080 Super Mobile
NVIDIA GeForce RTX 4060 Laptop GPU
...
specvp13 maya-05 + SPECviewperf 13 - specvp13 maya-05
min: 251.9 moyenne: 253.5 médian: 253.5 (30%) maximum: 255 fps
Intel Iris Plus Graphics G7 (Ice Lake 64 EU)
...
NVIDIA GeForce RTX 2070 Super Max-Q
NVIDIA GeForce RTX 2070 Super Mobile
NVIDIA GeForce RTX 4050 Laptop GPU
NVIDIA GeForce RTX 4060 Laptop GPU
...
NVIDIA GeForce RTX 4080 Laptop GPU
specvp13 energy-02 + SPECviewperf 13 - specvp13 energy-02
min: 17.14 moyenne: 17.2 médian: 17.2 (9%) maximum: 17.28 fps
...
NVIDIA GeForce RTX 2070 Super Max-Q
...
NVIDIA GeForce RTX 4090 Laptop GPU
specvp13 creo-02 + SPECviewperf 13 - specvp13 creo-02
min: 241.6 moyenne: 244.7 médian: 244.7 (40%) maximum: 247.7 fps
Intel Iris Plus Graphics G7 (Ice Lake 64 EU)
...
NVIDIA GeForce RTX 4070 Laptop GPU
NVIDIA GeForce RTX 4080 Laptop GPU
NVIDIA GeForce RTX 4090 Laptop GPU
specvp13 catia-05 + SPECviewperf 13 - specvp13 catia-05
min: 291.7 moyenne: 297.1 médian: 297.1 (36%) maximum: 302.4 fps
...
NVIDIA GeForce RTX 4080 Laptop GPU
NVIDIA GeForce RTX 4090 Laptop GPU
specvp13 3dsmax-06 + SPECviewperf 13 - specvp13 3dsmax-06
149.6 fps (27%)
...
NVIDIA GeForce RTX 4050 Laptop GPU
NVIDIA GeForce RTX 2070 Super Max-Q
...
NVIDIA GeForce RTX 4080 Laptop GPU
Cinebench R10 Cinebench R10 Shading (32bit) + Cinebench R10 - Cinebench R10 Shading (32bit)
min: 6830 moyenne: 6833 médian: 6833 (5%) maximum: 6836 points
...
NVIDIA Quadro P620
NVIDIA GeForce RTX 2070 Super Max-Q
AMD Radeon RX Vega 9
...
NVIDIA GeForce RTX 4080 Laptop GPU
Cinebench R11.5 Cinebench R11.5 OpenGL 64 Bit + Cinebench R11.5 - Cinebench R11.5 OpenGL 64 Bit
min: 145.4 moyenne: 158 médian: 158 (58%) maximum: 170.5 fps
...
NVIDIA GeForce RTX 4050 Laptop GPU
NVIDIA GeForce RTX 4080 Laptop GPU
NVIDIA GeForce RTX 4090 Laptop GPU
...
NVIDIA GeForce RTX 4080 Laptop GPU
Cinebench R15 Cinebench R15 OpenGL 64 Bit + Cinebench R15 - Cinebench R15 OpenGL 64 Bit
min: 219 moyenne: 234.3 médian: 234.3 (60%) maximum: 249.6 fps
...
AMD Radeon RX 7600S
NVIDIA GeForce RTX 4050 Laptop GPU
NVIDIA GeForce RTX 4080 Laptop GPU
NVIDIA GeForce RTX 4070 Laptop GPU
NVIDIA GeForce RTX 4090 Laptop GPU
...
Cinebench R15 OpenGL Ref. Match 64 Bit + Cinebench R15 - Cinebench R15 OpenGL Ref. Match 64 Bit
99.6 % (100%)
...
NVIDIA GeForce GTX 1050 Ti Max-Q
NVIDIA GeForce GTX 1050 Max-Q
...
LuxMark v2.0 64Bit - LuxMark v2.0 Room GPU
2539 Samples/s (11%)
...
NVIDIA GeForce GTX 1070 Mobile
NVIDIA GeForce RTX 4050 Laptop GPU
...
LuxMark v2.0 64Bit - LuxMark v2.0 Sala GPU
5183 Samples/s (9%)
...
...
NVIDIA GeForce RTX 4090 Laptop GPU
ComputeMark v2.1 - ComputeMark v2.1 Result
15892 points (17%)
...
NVIDIA GeForce RTX 2070 Super Max-Q
NVIDIA GeForce RTX 2070 Super Mobile
NVIDIA GeForce RTX 4050 Laptop GPU
NVIDIA GeForce RTX 2080 Super Mobile
AMD Radeon RX 7600S
...
NVIDIA GeForce RTX 4090 Laptop GPU
Power Consumption - Witcher 3 Power Consumption *
min: 218.9 moyenne: 227.6 médian: 227.6 (50%) maximum: 236.3 Watt
...
NVIDIA GeForce RTX 2070 Super Mobile
AMD Radeon RX 580 (Laptop)
NVIDIA GeForce RTX 4080 Laptop GPU
NVIDIA GeForce RTX 4090 Laptop GPU
NVIDIA GeForce RTX 2080 Super Mobile
Power Consumption - Witcher 3 ultra Power Efficiency
min: 0.2823 moyenne: 0.3 médian: 0.3 (30%) maximum: 0.2896 Points per Watt
...
Intel UHD Graphics Xe G4 48EUs
AMD Radeon RX 550X (Laptop)
NVIDIA GeForce GTX 1050 Ti Mobile
AMD Radeon RX Vega 10
NVIDIA GeForce GTX 1050 Ti Max-Q
NVIDIA Quadro P620
NVIDIA GeForce GTX 1050 Max-Q
...
Apple M2 Pro 16-Core GPU
- Amplitude des valeurs obtenues dans le benchmark avec cette carte graphique
- Valeur moyenne obtenue dans le benchmark avec cette carte graphique
* Plus les chiffres sont petits, plus les performances sont élevées
