NVIDIA GeForce RTX 3060 Laptop GPU
La Nvidia GeForce RTX 3060 Mobile (pour ordinateurs portables, GN20-E3, Max-P) est la troisième carte graphique Ampere destinée aux ordinateurs portables au début de 2021. Elle est basée sur la puce Ampère GA106 et offre une mémoire graphique GDDR6 de 6 Go avec un bus mémoire de 192 bits. Elle prend en charge PCIe 4.0 et sera disponible dans différentes variantes de 60 ou 115 Watt (TGP). En tant que paquet, la carte graphique pour ordinateur portable utilise GB5-256 et la taille de la puce est de 40x40mm. Le GPU prend en charge eDP 1.4b pour connecter le moniteur interne.
Il n'y a plus de variante Max-Q (anciennement utilisée pour les variantes à faible consommation) mais chaque OEM peut choisir de mettre en œuvre les technologies Max-Q (Dynamic Boost, Whisper Mode).
Les performances dépendent du réglage TGP et du refroidissement de l'ordinateur portable. En moyenne, elles devraient être similaires à celles de l'ancienne GeForce RTX 2070 Super Mobile et donc mieux adaptées aux jeux QHD (jeux très exigeants). Les jeux moins exigeants, comme Star Wars Squadrons, devraient être jouables en 4k avec les paramètres de détail maximum. La carte de bureau RTX 3060 Ti, qui porte le même nom, est nettement plus rapide.
La puce GA106 offre 3 840 UAL FP32, dont la moitié peut également exécuter des instructions INT32 (soit 1 920 UAL INT32). La RTX 3060 mobile n'aura que les 3 840 cœurs de la puce. Avec Turing, tous les shaders peuvent encore exécuter des instructions FP32 ou INT32. Selon Nvidia, les cœurs de raytracing et de tenseur de la puce ont également été améliorés. Les puces Ampere comprennent également un encodeur vidéo amélioré de 5e génération (NVENC pour H.264 et H.265) et un décodeur de 7e génération (pour divers formats, dont AV1).
La puce GA106 est fabriquée par Samsung en 8 nm (8N), ce qui n'est pas tout à fait à la hauteur du nœud de 7 nm de TSMC (utilisé par exemple par AMD et aussi pour la puce professionnelle GA100 d'Ampere).
GeForce RTX 3000 Gamme Nom de code GN20-E3 GA106 Architecture Ampere Pipelines 3840 - unifiés TMUs 120 ROPs 48 Raytracing Cores 30 Tensor / AI Cores 120 Fréquence du noyau interne 817 - 1702 (Boost) MHz Fréquence de la mémoire 14000 effective = 1750 MHz Largeur du bus mémoire 192 Bit Type de mémoire GDDR6 Quantité maximale possible de mémoire embarquée 6 GB Mémoire partagée non Memory Bandwidth 336 GB/s API DirectX 12_2, Shader 7.0, OpenGL 4.6 Consommation d'énergie 115 Watt(s) (60 - 115 Watt(s) TGP) technologie 8 nm PCIe 4.0 Displays HDMI 2.1, DisplayPort 1.4a Caractéristiques NVIDIA DLSS, NVIDIA Reflex, Resizable BAR, NVIDIA Broadcast, NVIDIA Ansel, NVIDIA ShadowPlay®, NVIDIA G-SYNC®, Advanced Optimus, Nvidia Max-Q, Dynamic Boost Dimension de l'ordinateur portable de grandes dimensions (en remplacement d'un ordinateur de bureau) Date de présentation 04.01.2021
Benchmarks Performance Rating - 3DMark 11 + Fire Strike + Time Spy
32.4 pt (35%)
...
NVIDIA GeForce RTX 2070 Super Max-Q -8%
NVIDIA GeForce RTX 3060 Laptop GPU
NVIDIA GeForce GTX 1070 Mobile 7%
...
3DMark - 3DMark Time Spy Score
min: 6473 moyenne: 8087 médian: 8264 (43%) maximum: 9677 Points
GPU TDP ? TDP 65 W TDP 70 W TDP 75 W TDP 80 W TDP 85 W TDP 95 W TDP 100 W TDP 105 W TDP 115 W TDP 120 W TDP 125 W TDP 130 W TDP 140 W 85% 68% 75% 78% 76% 76% 77% 86% 83% 100% 88% 86% 89% 95%
...
NVIDIA GeForce RTX 2070 Super Max-Q -6%
NVIDIA GeForce RTX 3060 Laptop GPU
NVIDIA GeForce RTX 2070 Super Mobile 3%
...
3DMark - 3DMark Time Spy Graphics
min: 6285 moyenne: 7969 médian: 8068.5 (37%) maximum: 9235 Points
GPU TDP ? TDP 65 W TDP 70 W TDP 75 W TDP 80 W TDP 85 W TDP 95 W TDP 100 W TDP 105 W TDP 115 W TDP 120 W TDP 125 W TDP 130 W TDP 140 W 88% 69% 76% 79% 78% 78% 82% 88% 85% 100% 91% 90% 93% 95%
...
NVIDIA GeForce RTX 2070 Super Max-Q -7%
NVIDIA GeForce RTX 3060 Laptop GPU
NVIDIA GeForce RTX 2070 Super Mobile 3%
NVIDIA GeForce RTX 2080 Super Mobile 29%
...
3DMark - 3DMark Ice Storm Unlimited Graphics
min: 116696 moyenne: 339251 médian: 360476 (48%) maximum: 519354 Points
GPU TDP 100 W TDP 120 W TDP 130 W 100% 59% 51%
...
NVIDIA GeForce GTX 1050 Max-Q -6%
NVIDIA GeForce GTX 1050 Ti Max-Q -4%
NVIDIA Quadro P2000 Max-Q -4%
NVIDIA GeForce RTX 3060 Laptop GPU
NVIDIA GeForce GTX 1070 Mobile 1%
...
3DMark - 3DMark Ice Storm Extreme Graphics
304456 Points (42%)
...
NVIDIA GeForce RTX 3060 Laptop GPU
3DMark - 3DMark Cloud Gate Score
min: 28859 moyenne: 44707 médian: 44523 (54%) maximum: 58475 Points
GPU TDP ? TDP 65 W TDP 70 W TDP 75 W TDP 80 W TDP 85 W TDP 95 W TDP 105 W TDP 115 W TDP 120 W TDP 125 W TDP 130 W TDP 140 W 70% 78% 59% 79% 79% 79% 72% 60% 100% 93% 81% 87% 95%
...
NVIDIA GeForce RTX 3060 Laptop GPU
NVIDIA GeForce RTX 2070 Super Mobile 1%
NVIDIA GeForce RTX 2070 Super Max-Q 2%
...
3DMark - 3DMark Cloud Gate Graphics
min: 33126 moyenne: 101418 médian: 109734 (45%) maximum: 136275 Points
GPU TDP ? TDP 65 W TDP 70 W TDP 75 W TDP 80 W TDP 85 W TDP 95 W TDP 105 W TDP 115 W TDP 120 W TDP 125 W TDP 130 W TDP 140 W 60% 51% 36% 77% 59% 89% 84% 60% 89% 100% 63% 91% 79%
...
NVIDIA GeForce GTX 1070 Mobile -2%
NVIDIA GeForce RTX 3060 Laptop GPU
NVIDIA GeForce RTX 2070 Super Max-Q 16%
...
3DMark - 3DMark Fire Strike Standard Score
min: 15062 moyenne: 18243 médian: 18451 (46%) maximum: 21179 Points
GPU TDP ? TDP 65 W TDP 70 W TDP 75 W TDP 80 W TDP 85 W TDP 95 W TDP 100 W TDP 105 W TDP 115 W TDP 120 W TDP 125 W TDP 130 W TDP 140 W 90% 75% 77% 83% 84% 83% 85% 85% 90% 100% 90% 92% 94% 98%
...
NVIDIA GeForce RTX 2070 Super Max-Q -1%
NVIDIA GeForce RTX 3060 Laptop GPU
NVIDIA GeForce RTX 2070 Super Mobile 2%
...
3DMark - 3DMark Fire Strike Standard Graphics
min: 16354 moyenne: 20191 médian: 20346.5 (38%) maximum: 23109 Points
GPU TDP ? TDP 65 W TDP 70 W TDP 75 W TDP 80 W TDP 85 W TDP 95 W TDP 100 W TDP 105 W TDP 115 W TDP 120 W TDP 125 W TDP 130 W TDP 140 W 94% 76% 81% 84% 83% 85% 89% 82% 93% 99% 91% 92% 98% 100%
...
NVIDIA GeForce RTX 3060 Laptop GPU
NVIDIA GeForce RTX 2070 Super Max-Q 0%
NVIDIA GeForce RTX 2070 Super Mobile 8%
...
3DMark - 3DMark Ice Storm Graphics
min: 124176 moyenne: 199105 médian: 140124 (19%) maximum: 333015 Points
GPU TDP 85 W TDP 125 W TDP 130 W 37% 42% 100%
...
AMD Radeon R9 M295X -9%
NVIDIA GeForce RTX 3060 Laptop GPU
AMD Radeon 680M 1%
NVIDIA GeForce GTX 1070 Mobile 30%
...
3DMark - 3DMark Night Raid
44997 Points (54%)
...
NVIDIA GeForce RTX 3060 Laptop GPU
3DMark - 3DMark Night Raid Graphics Score
86045 Points (48%)
...
NVIDIA GeForce RTX 3060 Laptop GPU
...
3DMark 11 - 3DM11 Performance Score
min: 14164 moyenne: 22555 médian: 22357.5 (45%) maximum: 28541 Points
GPU TDP ? TDP 65 W TDP 70 W TDP 75 W TDP 80 W TDP 85 W TDP 95 W TDP 100 W TDP 105 W TDP 115 W TDP 120 W TDP 125 W TDP 130 W TDP 140 W 83% 79% 82% 76% 72% 78% 77% 87% 65% 100% 84% 82% 85% 97%
...
NVIDIA GeForce RTX 3060 Laptop GPU
NVIDIA GeForce RTX 2070 Super Max-Q 2%
NVIDIA GeForce RTX 2070 Super Mobile 5%
...
3DMark 11 - 3DM11 Performance GPU
min: 13799 moyenne: 26180 médian: 26722 (38%) maximum: 30772 Points
GPU TDP ? TDP 65 W TDP 70 W TDP 75 W TDP 80 W TDP 85 W TDP 95 W TDP 100 W TDP 105 W TDP 115 W TDP 120 W TDP 125 W TDP 130 W TDP 140 W 88% 75% 83% 81% 74% 83% 87% 93% 68% 100% 93% 90% 96% 99%
...
NVIDIA GeForce RTX 3060 Laptop GPU
NVIDIA GeForce RTX 2070 Super Max-Q 4%
NVIDIA GeForce RTX 2070 Super Mobile 12%
...
3DMark 06 3DMark 06 - Standard 1280x1024 +
min: 37418 moyenne: 41961 médian: 41960.5 (63%) maximum: 46503 Points
GPU TDP 100 W TDP 105 W 100% 80%
...
NVIDIA GeForce RTX 2080 Super Mobile 0%
NVIDIA GeForce RTX 3060 Laptop GPU
NVIDIA GeForce RTX 2070 Super Mobile 3%
NVIDIA GeForce RTX 2070 Super Max-Q 3%
...
Cinebench R10 Cinebench R10 Shading (32bit) + Cinebench R10 - Cinebench R10 Shading (32bit)
min: 4955 moyenne: 9518 médian: 9518 (40%) maximum: 14081 points
GPU TDP ? TDP 130 W 35% 100%
...
Intel UHD Graphics G1 (Ice Lake 32 EU) -1%
AMD FirePro W4190M 0%
NVIDIA GeForce RTX 3060 Laptop GPU
Intel UHD Graphics Xe G4 48EUs 1%
AMD Radeon RX 550X (Laptop) 2%
...
Cinebench R11.5 Cinebench R11.5 OpenGL 64 Bit + Cinebench R11.5 - Cinebench R11.5 OpenGL 64 Bit
min: 77 moyenne: 108.5 médian: 108.5 (40%) maximum: 140 fps
GPU TDP ? TDP 130 W 100% 55%
...
NVIDIA Quadro P2000 Max-Q -8%
AMD Radeon Pro 460 -5%
NVIDIA GeForce RTX 3060 Laptop GPU
NVIDIA Quadro P600 5%
AMD Radeon 680M 5%
...
Cinebench R15 Cinebench R15 OpenGL 64 Bit + Cinebench R15 - Cinebench R15 OpenGL 64 Bit
min: 99.5 moyenne: 169.6 médian: 173 (47%) maximum: 219 fps
GPU TDP ? TDP 65 W TDP 70 W TDP 75 W TDP 80 W TDP 85 W TDP 95 W TDP 100 W TDP 105 W TDP 115 W TDP 120 W TDP 125 W TDP 130 W TDP 140 W 96% 100% 95% 87% 71% 93% 83% 76% 89% 95% 50% 68% 78% 91%
...
NVIDIA Quadro P620 -6%
NVIDIA GeForce RTX 3060 Laptop GPU
NVIDIA GeForce RTX 2080 Super Mobile 5%
...
Cinebench R15 OpenGL Ref. Match 64 Bit + Cinebench R15 - Cinebench R15 OpenGL Ref. Match 64 Bit
99.6 % (100%)
GPU TDP ? TDP 65 W TDP 70 W TDP 75 W TDP 80 W TDP 85 W TDP 95 W TDP 100 W TDP 105 W TDP 115 W TDP 120 W TDP 125 W TDP 130 W TDP 140 W 100% 100% 100% 100% 100% 100% 100% 100% 100% 100% 100% 100% 100% 100%
...
NVIDIA GeForce GTX 1050 Ti Max-Q 0%
NVIDIA Quadro P2000 Max-Q 0%
NVIDIA GeForce RTX 3060 Laptop GPU
...
Power Consumption - Furmark Stress Test Power Consumption - external Monitor *
min: 94.1 moyenne: 145.4 médian: 147 (23%) maximum: 202 Watt
GPU TDP 65 W TDP 70 W TDP 75 W TDP 85 W TDP 95 W TDP 100 W TDP 105 W TDP 115 W TDP 125 W TDP 130 W TDP 140 W 117% 116% 113% 108% 110% 105% 106% 101% 102% 104% 100%
...
NVIDIA GeForce RTX 3060 Laptop GPU
NVIDIA GeForce RTX 2070 Super Mobile 20%
...
0 15 30 45 60 75 90 105 120 135 150 165 180 195 Tooltip
Power Consumption - The Witcher 3 Power Consumption - external Monitor *
min: 107.5 moyenne: 145.9 médian: 143.5 (20%) maximum: 191 Watt
GPU TDP 65 W TDP 70 W TDP 75 W TDP 80 W TDP 85 W TDP 95 W TDP 100 W TDP 105 W TDP 115 W TDP 125 W TDP 130 W TDP 140 W 115% 115% 114% 115% 110% 110% 108% 108% 100% 105% 107% 102%
...
NVIDIA GeForce RTX 3060 Laptop GPU
NVIDIA GeForce RTX 2070 Super Max-Q 5%
...
0 15 30 45 60 75 90 105 120 135 150 165 180 195 Tooltip
Power Consumption - Witcher 3 Power Consumption *
min: 111 moyenne: 150.3 médian: 148.5 (33%) maximum: 195 Watt
