NVIDIA GeForce RTX 3080 Laptop GPU
Le GPU Nvidia GeForce RTX 3080 Laptop ou 3080 Mobile (pour les ordinateurs portables, GN20-E7) est la carte graphique la plus rapide pour les ordinateurs portables au début de 2021. Elle est basée sur la puce Ampère GA104-775-A1 et offre une mémoire graphique GDDR6 de 8 ou 16 Go avec un bus mémoire de 256 bits. Elle prend en charge PCIe 4.0 et sera disponible dans différentes variantes de 80 à 150 watts (TGP) (80, 90, 115, 125, 135, 145 et 150+ Watt). La carte graphique de l'ordinateur portable utilise le GB5-256 et la taille de la puce est de 40x40mm. Le GPU supporte l'eDP 1.4b pour connecter le moniteur interne.
Il n'y a plus de variante Max-Q (anciennement utilisée pour les variantes à faible consommation) mais chaque OEM peut choisir de mettre en œuvre les technologies Max-Q (Dynamic Boost, Whispermode).
Les performances dépendent du réglage TGP et du refroidissement de l'ordinateur portable. Au même niveau de TGP, le RTX3080 devrait être plus rapide que l'ancien modèle haut de gamme, le RTX 2080 Super Mobile et similaire au RTX 3070 de bureau. Cela signifie que le GPU devrait être bien adapté aux jeux 4k ou QHD avec des taux d'images élevés. La carte de bureau RTX 3080 du même nom est nettement plus rapide.
La puce GA104 offre 6 144 FP32 ALUs dont la moitié peut également exécuter des instructions INT32 (soit 3 072 INT32 ALUs). Avec Turing, tous les shaders peuvent encore exécuter des instructions FP32 ou INT32. Selon Nvidia, les cœurs de raytracing et de tenseur de la puce ont également été améliorés. Les puces Ampere comprennent également un encodeur vidéo amélioré de 5e génération (NVENC pour H.264 et H.265) et un décodeur de 7e génération (pour divers formats, dont AV1).
La puce GA104 est fabriquée par Samsung en 8 nm (8N), ce qui n'est pas tout à fait à la hauteur du nœud de 7 nm de TSMC (utilisé par exemple par AMD et aussi pour la puce professionnelle GA100 d'Ampere).
GeForce RTX 3000 Gamme Nom de code GN20-E7 GA104 Architecture Ampere Pipelines 6144 - unifiés TMUs 192 ROPs 96 Raytracing Cores 48 Fréquence du noyau interne 780 - 1100 - 1245 - 1710 (Boost) MHz Fréquence de la mémoire 14000 effective = 1750 MHz Largeur du bus mémoire 256 Bit Type de mémoire GDDR6 Quantité maximale possible de mémoire embarquée 16 GB Mémoire partagée non Memory Bandwidth 448 GB/s API DirectX 12_2, Shader 7.0, OpenGL 4.6 Consommation d'énergie 150 Watt(s) (80 - 150 Watt(s) TGP) Nombre de transistors 17.4 Billion Die Size 392 mm² technologie 8 nm PCIe 4.0 Displays HDMI 2.1, DisplayPort 1.4a Caractéristiques NVIDIA DLSS, NVIDIA Reflex, Resizable BAR, NVIDIA Broadcast, NVIDIA Ansel, NVIDIA ShadowPlay®, NVIDIA G-SYNC®, Advanced Optimus, Nvidia Max-Q, Dynamic Boost, VR-ready, Nvidia Omniverse Dimension de l'ordinateur portable de grandes dimensions (en remplacement d'un ordinateur de bureau) Date de présentation 12.01.2021
Benchmarks Performance Rating - 3DMark 11 + Fire Strike + Time Spy
47.8 pt (52%)
...
NVIDIA GeForce RTX 3080 Laptop GPU
3DMark - 3DMark Time Spy Score
min: 6499 moyenne: 10491 médian: 10763 (56%) maximum: 13067 Points
GPU TDP ? TDP 90 W TDP 95 W TDP 100 W TDP 105 W TDP 125 W TDP 130 W TDP 140 W TDP 150 W TDP 155 W TDP 165 W 83% 68% 75% 81% 82% 89% 92% 94% 93% 100% 95%
...
NVIDIA GeForce RTX 2080 Super Mobile 0%
NVIDIA GeForce RTX 3080 Laptop GPU
...
3DMark - 3DMark Time Spy Graphics
min: 6407 moyenne: 10735 médian: 10836 (50%) maximum: 13210 Points
GPU TDP ? TDP 90 W TDP 95 W TDP 100 W TDP 105 W TDP 125 W TDP 130 W TDP 140 W TDP 150 W TDP 155 W TDP 165 W 81% 69% 73% 77% 79% 85% 89% 91% 93% 100% 93%
...
NVIDIA GeForce RTX 2080 Super Mobile -4%
NVIDIA GeForce RTX 3080 Laptop GPU
3DMark - 3DMark Ice Storm Unlimited Graphics
min: 444648 moyenne: 538152 médian: 538549 (72%) maximum: 645075 Points
GPU TDP 95 W TDP 100 W TDP 105 W TDP 150 W TDP 165 W 75% 81% 91% 94% 100%
...
NVIDIA GeForce RTX 2070 Super Max-Q -14%
NVIDIA GeForce RTX 2070 Super Mobile -12%
NVIDIA GeForce RTX 3080 Laptop GPU
3DMark - 3DMark Ice Storm Extreme Graphics
415335 Points (57%)
...
NVIDIA GeForce RTX 3080 Laptop GPU
3DMark - 3DMark Cloud Gate Score
min: 30210 moyenne: 48338 médian: 50076 (61%) maximum: 65479 Points
GPU TDP 95 W TDP 100 W TDP 105 W TDP 125 W TDP 130 W TDP 140 W TDP 150 W TDP 155 W TDP 165 W 68% 87% 81% 97% 90% 100% 81% 100% 92%
...
NVIDIA GeForce RTX 2070 Super Mobile -7%
NVIDIA GeForce RTX 2070 Super Max-Q -6%
NVIDIA GeForce RTX 3080 Laptop GPU
NVIDIA GeForce RTX 2080 Super Mobile 11%
3DMark - 3DMark Cloud Gate Graphics
min: 38816 moyenne: 119529 médian: 128191 (52%) maximum: 192950 Points
GPU TDP 95 W TDP 100 W TDP 105 W TDP 125 W TDP 130 W TDP 140 W TDP 150 W TDP 155 W TDP 165 W 51% 54% 54% 65% 52% 83% 54% 100% 72%
...
NVIDIA GeForce RTX 2070 Super Max-Q -2%
NVIDIA GeForce RTX 3080 Laptop GPU
NVIDIA GeForce RTX 2070 Super Mobile 2%
NVIDIA GeForce RTX 2080 Super Mobile 18%
...
3DMark - 3DMark Fire Strike Standard Score
min: 13393 moyenne: 22401 médian: 22801 (57%) maximum: 27685 Points
GPU TDP ? TDP 90 W TDP 95 W TDP 100 W TDP 105 W TDP 125 W TDP 130 W TDP 140 W TDP 150 W TDP 155 W TDP 165 W 86% 64% 82% 88% 87% 98% 100% 100% 93% 99% 98%
...
NVIDIA GeForce RTX 2070 Super Mobile -17%
NVIDIA GeForce RTX 2080 Super Mobile -4%
NVIDIA GeForce RTX 3080 Laptop GPU
3DMark - 3DMark Fire Strike Standard Graphics
min: 16455 moyenne: 27596 médian: 27316.5 (51%) maximum: 32366 Points
GPU TDP ? TDP 90 W TDP 95 W TDP 100 W TDP 105 W TDP 125 W TDP 130 W TDP 140 W TDP 150 W TDP 155 W TDP 165 W 81% 78% 78% 76% 83% 89% 88% 94% 80% 100% 95%
...
NVIDIA GeForce RTX 2080 Super Mobile -10%
NVIDIA GeForce RTX 3080 Laptop GPU
3DMark - 3DMark Ice Storm Graphics
min: 40654 moyenne: 251400 médian: 251400 (34%) maximum: 462145 Points
...
AMD Radeon 680M -20%
NVIDIA GeForce RTX 3080 Laptop GPU
NVIDIA GeForce GTX 1070 Mobile 3%
AMD Radeon RX 580 (Laptop) 7%
...
3DMark - 3DMark Night Raid
min: 27201 moyenne: 39663 médian: 39662.5 (48%) maximum: 52124 Points
...
NVIDIA GeForce RTX 3080 Laptop GPU
3DMark - 3DMark Night Raid Graphics Score
min: 33157 moyenne: 73983 médian: 73982.5 (41%) maximum: 114808 Points
...
NVIDIA GeForce RTX 3080 Laptop GPU
...
3DMark 11 - 3DM11 Performance Score
min: 24180 moyenne: 29201 médian: 29220 (59%) maximum: 32922 Points
GPU TDP ? TDP 90 W TDP 95 W TDP 100 W TDP 105 W TDP 125 W TDP 130 W TDP 140 W TDP 150 W TDP 155 W TDP 165 W 100% 79% 85% 88% 92% 97% 95% 97% 96% 93% 98%
...
NVIDIA GeForce RTX 2080 Super Mobile -1%
NVIDIA GeForce RTX 3080 Laptop GPU
...
3DMark 11 - 3DM11 Performance GPU
min: 31288 moyenne: 38569 médian: 38470.5 (55%) maximum: 43744 Points
GPU TDP ? TDP 90 W TDP 95 W TDP 100 W TDP 105 W TDP 125 W TDP 130 W TDP 140 W TDP 150 W TDP 155 W TDP 165 W 99% 79% 78% 80% 84% 90% 90% 93% 97% 100% 95%
...
NVIDIA GeForce RTX 2080 Super Mobile -9%
NVIDIA GeForce RTX 3080 Laptop GPU
...
Cinebench R15 Cinebench R15 OpenGL 64 Bit + Cinebench R15 - Cinebench R15 OpenGL 64 Bit
min: 115 moyenne: 176.7 médian: 180 (48%) maximum: 250 fps
GPU TDP 90 W TDP 95 W TDP 100 W TDP 105 W TDP 125 W TDP 130 W TDP 140 W TDP 155 W TDP 165 W 100% 80% 74% 89% 83% 78% 87% 76% 91%
...
NVIDIA Quadro P620 -10%
NVIDIA GeForce RTX 3080 Laptop GPU
NVIDIA GeForce RTX 2080 Super Mobile 1%
...
Cinebench R15 OpenGL Ref. Match 64 Bit + Cinebench R15 - Cinebench R15 OpenGL Ref. Match 64 Bit
99.6 % (100%)
GPU TDP 90 W TDP 95 W TDP 100 W TDP 105 W TDP 125 W TDP 130 W TDP 140 W TDP 155 W TDP 165 W 100% 100% 100% 100% 100% 100% 100% 100% 100%
...
NVIDIA GeForce GTX 1050 Max-Q 0%
NVIDIA GeForce RTX 3080 Laptop GPU
...
LuxMark v2.0 64Bit - LuxMark v2.0 Room GPU
min: 4895 moyenne: 4904 médian: 4903.5 (22%) maximum: 4912 Samples/s
...
NVIDIA GeForce RTX 2080 Super Mobile -23%
NVIDIA GeForce RTX 3080 Laptop GPU
LuxMark v2.0 64Bit - LuxMark v2.0 Sala GPU
min: 11220 moyenne: 11236 médian: 11235.5 (20%) maximum: 11251 Samples/s
...
NVIDIA GeForce RTX 2080 Super Mobile -27%
NVIDIA GeForce RTX 3080 Laptop GPU
ComputeMark v2.1 - ComputeMark v2.1 Result
min: 24646 moyenne: 26511 médian: 26511 (51%) maximum: 28376 points
...
NVIDIA GeForce RTX 2080 Super Mobile -35%
NVIDIA GeForce RTX 3080 Laptop GPU
Power Consumption - Furmark Stress Test Power Consumption - external Monitor *
min: 122 moyenne: 176.5 médian: 169 (26%) maximum: 254 Watt
GPU TDP 90 W TDP 95 W TDP 100 W TDP 105 W TDP 125 W TDP 130 W TDP 140 W TDP 165 W 114% 116% 120% 111% 110% 109% 105% 100%
...
NVIDIA GeForce RTX 2070 Super Mobile -1%
NVIDIA GeForce RTX 3080 Laptop GPU
0 15 30 45 60 75 90 105 120 135 150 165 180 195 210 225 240 255 Tooltip
Power Consumption - The Witcher 3 Power Consumption - external Monitor *
min: 124 moyenne: 183.6 médian: 180 (25%) maximum: 244 Watt
GPU TDP 95 W TDP 100 W TDP 105 W TDP 125 W TDP 130 W TDP 140 W TDP 165 W 113% 117% 108% 106% 106% 102% 100%
...
NVIDIA GeForce RTX 2070 Super Max-Q -17%
NVIDIA GeForce RTX 3080 Laptop GPU
0 15 30 45 60 75 90 105 120 135 150 165 180 195 210 225 240 Tooltip
Power Consumption - Witcher 3 Power Consumption *
min: 123 moyenne: 186.6 médian: 189 (42%) maximum: 297 Watt
GPU TDP 90 W TDP 95 W TDP 100 W TDP 105 W TDP 125 W TDP 130 W TDP 140 W TDP 155 W TDP 165 W 136% 141% 143% 127% 119% 120% 116% 100% 105%
...
NVIDIA GeForce RTX 2070 Super Max-Q -16%
NVIDIA GeForce GTX 1070 Mobile -4%
NVIDIA GeForce RTX 3080 Laptop GPU
NVIDIA GeForce RTX 2070 Super Mobile 2%
AMD Radeon RX 580 (Laptop) 6%
...
